Case IH Farmall 75C
Description
The Case IH Farmall 75C is a compact and highly efficient tractor designed for light to medium agricultural tasks. With only 268 hours of work, this machine is nearly new and has minimal wear on both the 16.9 R30 front tires and 6.50-16 rear tires, ensuring long-term performance and reliability. Ideal for smaller farms or specialized work, the Farmall 75C provides excellent fuel efficiency, easy maneuverability, and a smooth operator experience.
Specifications
| Stock Number | PR-3O9KR |
|---|---|
| Model | Case IH Farmall 75C |
| Year | Not specified |
| Operating Hours | 268 hours |
| Engine Type | 4 cylinders, Diesel |
| Displacement | 3.4 L |
| Power | 75 hp (55 kW) |
| Max Torque | 305 Nm |
| Transmission | 12-speed mechanical transmission |
| Max Speed | 40 km/h |
| Weight | Normal weight |
| Fuel Tank Capacity | 70 L |
| Front Tire Dimensions | 16.9 R30 |
| Rear Tire Dimensions | 6.50-16 |
| Tire Wear | 0% |
| Overall Length | 3,000 mm |
| Overall Width | 1,800 mm |
| Overall Height | 2,200 mm |
| Wheelbase | 2,200 mm |
| Ground Clearance | 350 mm |
| Front Lift Capacity | 1,500 kg |
| Rear Lift Capacity | 2,000 kg |
| Hydraulic Flow Rate | 55 L/min |
| Hydraulic Pumps | 1 piston pump |
| Number of Valves | 2 |
Available Options:
-
Cab:
- Open station (no cab)
- Optional cab with air conditioning
-
Hydraulic System:
- Standard hydraulic system (55 L/min)
- Rear remotes for easy implement connections
-
Transmission:
- 12-speed transmission for precise speed control
- Hydraulic shuttle for smooth direction changes
-
Axles and Tires:
- Compact design for better maneuverability in narrow spaces
- Low ground pressure to protect soil
-
PTO:
- 540 rpm PTO for typical field work
-
Braking and Safety:
- Hydraulic disc brakes for smooth braking
- Parking brake
-
Steering System:
- Power steering for easy handling
-
Comfort Features:
- Comfortable seat
- Basic radio system for operator convenience
